Chapter 4. Status
4-6 MX2800 User Manual 61200290L1-1
Card A/Card B
These fields display the current state of the two controller cards.
Possible states for the controller cards are listed in the following
chart:
Protection
This field lists the type of protection mode currently active. Possible
states are listed in the following chart:
Condition Description
Not Installed No controller card is installed in this slot.
Stand By The controller card is ready to pass data, but is
currently acting as a backup card.
Active The controller card is acting as the primary card.
Failure The controller card has failed and needs to be re-
placed.
Condition Description
Network Both controller cards are installed and everything is
healthy. The unit is in full Network Protection Mode.
Circuit Unit is in Circuit Protection Mode and everything is
healthy,
or
unit is in Network Protection Mode and a failure on
the network has occurred.
None One controller card is installed,
or
the unit is in Circuit Protection Mode and the sec-
ondary card has failed.
