Chapter 2. Installation and Operation
2-10 MX2800 User Manual 61200290L1-1
Craft Port
The Craft port, an 8-pin modular jack, provides connection to a VT
100 EIA-232 compatible interface (using the supplied 8-pin
modular to DB-9 female connector and the 8-pin to 8-pin modular
cable).
Establishing Terminal Connection
To connect the MX2800 to a VT 100 terminal, follow this procedure:
1. Configure the VT 100 terminal for 9600, 19200, 38400, or 57600
baud, 8-bit characters, no parity, and one stop bit (xxxx, 8N1).
2. Using the ADTRAN-provided terminal interface cable adapter,
connect the DTE port of a terminal to the 8-pin modular jack
labeled
CRAFT on the MX2800 front panel.
3. Initialize the terminal session.
4. Press
Enter repeatedly until the password prompt appears.
5. Enter the password. The factory default password is
adtran (all
lower-case). The
M
AIN
menu appears. See Figure 2-5 on page
2-11.
6. Make selections by entering the number corresponding to the
chosen parameter. Press
ESC on the keyboard to return to the
previous screen. End a terminal session by selecting
L
OGOUT
from the
M
AIN
menu or by pressing Ctrl-C at any time.
