ADTRAN MX2800 - Table A-4. Amp Pin Assignments

Appendix A. Pinouts
61200290L1-1 MX2800 User Manual A-3
Table A-4. Amp Pin Assignments
Pin Function Pin
1 TIP 1 RING 1 33
2 TIP 2 RING 2 34
3 TIP 3 RING 3 35
4 TIP 4 RING 4 36
5 TIP 5 RING 5 37
6 TIP 6 RING 6 38
7 TIP 7 RING 7 39
8 TIP 8 RING 8 40
9 TIP 9 RING 9 41
10 TIP 10 RING 10 42
11 TIP 11 RING 11 43
12 TIP 12 RING 12 44
13 TIP 13 RING 13 45
14 TIP 14 RING 14 46
15 TIP 15 RING 15 47
16 TIP 16 RING 16 48
17 TIP 17 RING 17 49
18 TIP 18 RING 18 50
19 TIP 19 RING 19 51
20 TIP 20 RING 20 52
21 TIP 21 RING 21 53
22 TIP 22 RING 22 54
23 TIP 23 RING 23 55
24 TIP 24 RING 24 56
25 TIP 25 RING 25 57
26 TIP 26 RING 26 58
27 TIP 27 RING 27 59
28 TIP 28 RING 28 60
29 61
30 62
31 63
32 FGND FGND 64
Table A-4 applies to both the In and Out DSX1/E1 Amp connectors.
