61200290L1-1 MX2800 User Manual A-1
Appendix A
Pinouts
The following tables give the pin assignments for the connectors
located on the MX2800. For more information on these connectors,
see the chapter Installation and Operation on page 2-1.
Table A-1. Craft Port Pin Assignments
RJ Pin# DB-9 Function Direction
15GND
27RTSI
33TDI
46DSRO
52RDO
68CTS*O
74DTRI
8 1 DCD O
- 9 not used -
*Used for hardware flow control.
