Chapter 3. Configuration
3-28 MX2800 User Manual 61200290L1-1
UTILITIES
The
U
TILITIES
menu (see Figure 3-17) allows you to view MX2800
system information (including self-test results) for both controller
cards, revert to default configuration settings, flash-load a new
version of software, and reset the system. Possible results for the
self-test are listed in the chart following Figure 3-17.
Figure 3-17. System Utilities Menu
If the self test results are... Then...
PASS the self test was successful and
the unit is ready to use.
BAD RAM DATA
BAD RAM ADDRESS
BAD CODE CHECKSUM
BAD BOOT SECTOR
IOX PROGRAM FAILURE
AFE PROGRAM FAILURE
MODEM FAILURE
ETHERNET FAILURE
contact ADTRAN Technical Sup-
port. See the inside back cover of
this manual for more information.
CONFIGURATION CORRUPT select
S
AVE
C
ONFIGURATION
from
the main
C
ONFIGURATION
menu.
If condition persists, contact
ADTRAN Technical Support.
