61200290L1-1 MX2800 User Manual 2-1
Chapter 2
Installation and Operation
UNPACK, INSPECT, POWER UP
Receiving Inspection
Carefully inspect the MX2800 for any damage that might have
occurred in shipment. If damage is suspected, file a claim
immediately with the carrier and contact ADTRAN Technical
Support (see the end of this manual for phone numbers). Keep the
original shipping container to use for future shipment or
verification of damage during shipment.
ADTRAN Shipments Include
The following items are included in ADTRAN shipments of the
MX2800.
• MX2800 unit
• DC or AC power supply (two power supplies come with the
Redundant Versions)
• Controller card (two cards come with the Redundant Versions)
• 8-pin to 6-pin modular cable (modem version only)
• 8-pin to 8-pin modular cable
• 8-pin modular to DB-9 female connector
• Two 4-position terminal lug connectors
• 3-position terminal lug connector
• Six-foot AC power cord (AC Versions only)
