Chapter 2. Installation and Operation
2-14 MX2800 User Manual 61200290L1-1
DS3
green solid Normal (All OK)
red blinking LOS
red solid AIS, LOF, RAI, Idle Alarms
amber solid In Test (Local)
amber blinking In Test (Remote)
red/amber alternating In Test + Alarms
ALM
green solid Normal (No Alarm)
red blinking Critical Alarm
red solid Non-Critical Alarm
amber blinking Critical Alarm Suppressed
(
ACO button was pushed)
amber solid Non-Critical Alarm Sup-
pressed (
ACO button was
pushed)
PRF
green solid Normal (All OK)
red flash (once per event) Single/Burst CV
red blinking Continuous Code Violations
red solid XCV Threshold Exceeded
(see
XCV Threshold on
page 3-4)
Table 2-2. LED Conditions for Active Cards (Continued)
LED State Card Condition
