DS3 Alarm Traps (Far-End Active Cards)
Trap If enabled, the unit issues a trap when...
LOS the remote unit’s active controller card has lost
the network Rx signal.
OOF the remote unit’s active controller card detects
a framing loss from the network.
AIS the remote unit’s active controller card is re-
ceiving an AIS (blue) alarm condition from the
network.
RAI the remote unit’s active controller card is re-
ceiving an RAI (yellow) alarm from the network.
This alarm is a signal sent back toward the
source of a failed transmit circuit. The X-bits
(X1 and X2) are set to zero.
IDLE the remote unit’s active controller card detects
an idle sequence from the network. Service is
immediately available for use.
DS3 Eqpt Fail
SA
the remote unit’s active controller card is re-
ceiving a service-affecting equipment failure
message from the network.
DS3 Eqpt Fail
NSA
the remote unit’s active controller card is re-
ceiving a non-service-affecting equipment fail-
ure message from the network.
Comn Eqpt Fail
NSA
the remote unit’s active controller card is re-
ceiving a common equipment failure message
from the network.
