To set host mode in the Total Access 3000/3010 shelf, do the following:
1. Logon to the system.
For details, go to: DLP-716
2. From the Total Access Menu, select option 1, System Controller, and press
<Enter>.
3. From the System Controller Menu, select option 2, Provisioning, and press
<Enter>.
4. From the Provisioning Menu, select option 1, General, and press <Enter>.
5. From the General Menu, select option 1, Management Ports, and press <Enter>.
6. From the Management Ports Menu, select option 5, Interbank Comm. Mode, and
press <Enter>.
7. From the Interbank Comm. Mode Menu, select option 1, Host, and press <Enter>.
8. Return to the Main Menu by pressing <Esc>.
9. Continue with section 1.14.8 to provision the remaining items.
1.14.8 Provision Remaining Items on SCU
Provisioning the remaining items before enabling the RS-485 bus.
1. From the Provisioning Menu, select option 1, General, and press <Enter>.
2. From the General Menu, select option 1, Management Ports, and press <Enter>.
3. From the Management Ports Menu, select option 3, Admin Port Baud Rate, and
press <Enter>.
4. Set the desired baud rate by selecting the corresponding number and press
<Enter>.
5. The current menu will now be the Management Ports Menu.
6. From the Management Ports Menu, select option 4, Admin Port Communications,
and press <Enter>.
7. Set the port communications to Menus by selecting option 1, and press <Enter>.
8. The current menu will now be the Management Ports Menu.
9. Press <Esc> once to return to the General Menu.
10. From the General Menu, select option 2, Date, and press <Enter>.
11. Enter the correct Date and press <Enter>.
12. The current menu will now be the General Menu.
13. From the General Menu, select option 3, Time, and press <Enter>.
14. Enter the correct Time and press <Enter>.
15. The current menu will now be the General Menu.
