Total Access
®
3000/3010 System Manual
6TADLP743-1E
TOTAL ACCESS
3000/3010
DLP-743
Page 3 of 4
© 2003, ADTRAN, Inc.
Perform Steps Below in the Order Listed
3.) For an OC-3 Mux, an additional APS setting is located under the
Provisioning menu, option 3, Switching Type.
a ) From the Total Access 3000 main menu, select option 2, “Common A”.
b) Select option 7, “Provisioning”.
c) Select option 3, “Switching Type”.
d) Set Switching Type to “Line” or “Path”.
LINE – switches based on the Line (K1, K2) indicators.
PATH – switches based on the STS-1 path level monitoring.
NOTE
Ensure that both units are set for the same Switching Type, Line or Path. If
Linked Provisioning is ‘Enabled’, setting the Switching Type on one unit will
automatically transfer that setting to the other unit.
4.) If Linked Provisioning is “Disabled”, manually set MUX B to the
same Switching Type setting as MUX A.
a) From the Total Access 3000 main menu, select option 2, “Common A”.
b) Select option 7, “Provisioning”.
c) Select option 3, “Switching Type”.
d) Set Switching Type to “Line” or “Path”.
1.2.2 Faceplate APS Button
1. Please note the following functions of the faceplate APS button.
• When activated while simultaneously depressing the Test/Enable switch
on the stand by unit, a switch to protection is forced.
• When activated while simultaneously depressing the Test/Enable switch
from the on line unit, the APS Lockout Status is toggled.
NOTE
Performing a Perform APS switch (option 2) from the Protection Configuration
menu will override an APS Lockout Status of INHIBIT.
To Next Page
