Total Access
®
3000/3010 System Manual
6TADLP743-1E
TOTAL ACCESS 3000/3010
DLP-743
Page 4 of 4
© 2003, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.2.3 Facpelate APS LED Indicators
Upon installation and provisioning of the Total Access 3000 MUX
modules, the faceplate LEDs should read as in Table 1.
A Flashing Yellow POWER LED indicates an Out-of-Service, Unassigned Service
State. On the DS3 MX this LED will be Solid Yellow when in the Unassigned State.
gnikroWtcetorP
REWOPwolleYgnihsalFREWOPwolleYgnihsalF
SUTATSdeRSUTATSdeR
TSETffOTSETffO
TUOKCOLffOTUOKCOL)WOLLAroftesfi(ffO
)TIBIHNIroftesfi(wolleY
ENILNOffOENILNOffO
Table 1. Faceplate LEDs
1.2.4 Disable Protection Switching
1. Disabling protection switching.
1.) Access the Main Menu of both Total Access 3000 MUX units and select
option 7, Protection Configuration.
2.) Select option 1, APS Lockout Status, and toggle from ALLOW to
INHIBIT. Ensure that both Mux modules are set for an APS Lockout
Status of INHIBIT.
CAUTION
In this configuration, transmission to the network will be lost if the online mux
is rendered out-of-service.
NOTE
In this configuration, the ONLINE MUX (indicated by faceplate LED)
is transmitting to the network while both MUX units are receiving
from the network and distributing to the access modules.
To Next Page
