6TAENG201-1E
TOTAL ACCESS 3000/3010
ENG-201
Page 12 of 32
© 2002, ADTRAN, Inc. Total Access
®
3000/3010 System Manual
The following guideline is intended to aid the designer and planner for installations of
Total Access 3000/3010 shelves and meeting NEBS heat release objectives. Since the
Total Access platform supports multiple technologies that produce a wide range of
heat, much forethought should be given to the installation and possible future
expansion. Depending on the technology employed, various scenarios and shelf
densities can be achieved. Reference Figure 1 and Figure 2 for examples of frame
installations.
