ADTRAN Total Access 3000 - Page 67

6TAENG201-1E
TOTAL ACCESS 3000/3010
ENG-201
Page 13 of 32
Total Access
®
3000/3010 System Manual
© 2002, ADTRAN, Inc.
Figure 1. Low Power Configuration (DSX-1, HD10)
Example:
All HD-10
9 @ 108 W = 972 W
-or-
All DSX-1
10 @ 78.3 W = 705 W
Fuse/Alarm #2
Fuse/Alarm #1
Chassis #1
Kick Panel
Chassis #2
Chassis #3
Chassis #4
Chassis #5
Chassis #6
Chassis #7
Chassis #8
Chassis #9 - Limit HD10
Chassis #10 - Limit DSX-1
Note: Higher Density
May Be Achieved with
Extenders
