10
2.4 AIR CLEANER MAINTENANCE
(1) Lift up on the rear of the seat.
(2) Pull the seat back and free of the tabs.
NOTE: When reinstalling seat, make sure
the slots in the seat engage the tabs in the
fuel tank.
(3) Remove clips from air box cover (A) and
remove cover. Inspect the gasket. It should
adhere tightly to the cover and seal all the
way around.
(4) Install the new one.
(5) Reinstall filter on main filter mount. Place
filter clamp over the assembly and tighten.
NOTE: Apply a small amount of general
purpose grease to the sealing edges of the filter
before reinstalling.
