19
4. LUBRICATION
4.1 Service Information
4.2 Trouble Shooting
4.3 Engine Oil Level
4.4 Engine Oil & Filter Change
4.5 Oil Pump Removal /Installation
4.1 SERVICE INFORMATION
GENERAL
This section describes inspection and replacement of the engine oil, oil filter screen and
assembly of the oil pump.
Fill the oil pump with clean oil when reassembling the pump.
SPECIFICATIONS
Engine Oil Capacity 0.8-1.0 Liters /
Engine Oil Recommendations Viscosity: (SAE 15W-40)
API Service classification: SF-SG
OIL PUMP STANDARD SERVIC LIMIT
Cover-to-rotor clearance --------- 0.12
Rotor tip clearance -------- 0.12
End clearance 0.01-0.10 0.2
TORQUE VALUE
Oil Drain Bolt 14 ft. lbs. (19 Nm)
