98
11.9 HEADLIGHT LAMP REPLACEMENT
NOTE: Allow lamp to cool before proceeding. Do
not touch a halogen lamp with bare fingers. Oil from
your skin leaves a residue, causing a hot spot which
will shorten the life of the lamp. Hold the bulb by the
base only.
To access the headlight assembly without removing
the front cover, reach up under the front cab.
Rotate the socket (2) counterclockwise and pull it
away from the headlight assembly.
Install the new headlamp.
Reinstall all components.
TAILLIGHT/BRAKELIGHT LAMP
REPLACEMENT
If the taillight/brakelight does not work the
lamp may need to be replaced.
(Step 1)From the rear of the taillight
remove two screws (1) holding lens
cover in place and remove lens cover.
(Step 2)Remove lamp (2) and replace it
with recommended lamp.
Reinstall the lens cover removed in Step 1.
Test the taillight/brakelight.
