66
8.4 THROTTLE HOUSING
Disassembly
Unscrew the screws on the throttle housing
cover.
Remove throttle housing cover and gasket.
Disconnect throttle cable from the throttle arm
and remove from the throttle housing.
Assembly is in the reverse order of disassembly.
8.5 FRONT WHEEL
Remove
Raise the front wheels off the ground by placing
a jack or other support under the frame.
Remove the front wheel nuts, washer and
wheels.
Installation
Install and tighten the four-wheel nuts torque:
54 N.m (40 lbs.ft ) Remember put a cotter pin in
the castle nut.
8.6 FRONT BRAKES
FRONT PAD REMOVAL
Elevate and support front of machine.
CAUTION: Use care when supporting vehicle
so that it does not tip or fall. Severe injury or
damage may occur if machine tips or falls.
.
Remove the front wheel. With the caliper
installed loosen the brake caliper slide bolts (A).
