14
2.9 WHEELS AND TIRES
Inspect the tire surface for cuts, nails or other
sharp objects.
Check the tire pressure at cold tire conditions.
The standard tire pressure is 4psi.
(0.28kgf/cm
2
)
2.10 STEERING SYSTEM
Check the free play of the steering shaft with
the front wheels, turned straight ahead. When
there is excessive play, inspect the tie-rod,
kingpin bushing and ball joint.
Steering shaft holder bushing
Remove the front fender.
Remove the steering shaft holder and check the
steering shaft bushing for wears or damage.
If the bushing is worn or damaged, change a
new one.
Grease the steering shaft bushing and install the
parts in the reverse order of removal.
Torque: steering shaft holder bolt: 33N.m (24
Ft. lbs)
