22
13. Place gear selector in neutral and set parking
brake.
14. Start the engine and let it idle for one to two
minutes, Stop the engine and inspect for
leaks.
15. Re-check the oil level and add oil as
necessary to bring the level to the upper
level.
16. Dispose of used filter and oil properly.
ENGINE OIL CAPACITY: 1.2 liter at draining.
4.5 OIL PUMP REMOVAL /
INSTALLATION
1. Remove stator housing bolts and remove
housing.
2. Remove the start drive gear and shaft by
pulling the shaft and tilting the gear slightly.
Flywheel removal generally is not required.
3. Measure the OD of the starter drive shaft on
both ends for out-of-round.
4. Measure the ID of the bushing in the stator
housing (A) and in the crankcase (B) in two
directions 90°apart to determine if
out-of-round. Calculate clearance. Replace
components if clearance is excessive.
5. Inspect gear teeth on starter drive. Replace
starter drive if gear teeth are cracked, worn,
or broken.
