7. TRANSMISSION & KICK STARTER
7.1 SERVUCE INFORMATION
7.2 TROUBLESHOOTING
7.3 C.V.T SYSTEM DISASSEMBLY / DRIVE CLUTCH
7.4 KICK STARTER ASSEMBLY
7.5 KICK STARTER ASSEMBLY
7.6 C.V.T REASSEMBLY
7.1 SERVICE INFORMATION
If the drain tube ass’y fills with water, the tube should be drained.
SPECIFICATIONS
ITEM STANDARD (mm) SERVICE LIMIT (mm)
Driven the width 19.8-20.2 19.0
Weight roller O.D. 17.9-18.1 17.40
Movable drive face I.D. 27.98-28.0 28.03
Drive face collar I.D. 24.06-24.09 24.098
Drive face boss O.D. 23.96-23.98 23.92
Clutch outer I.D. 124.8-125.2 125.5
Clutch weight lining thickness -------------- 1.5
Driven face spring length 168.4-169.4 164.0
TORQUE VALUES
Clutch outer nut 55 N-m (5.5 kg-m)
Drive face nut 55 N-m (5.5 kg-m)
