34
5.4 CYLINDER HEAD REMOVAL
Loosen each of the four cylinder head bolts
evenly 1/4 turn each time in a cross pattern
until loose.
Remove bolts (A)
Remove cylinder head and head gasket.
CYLINDER HEAD DISASSEMBLY
Using a valve spring compressor, compress
the valve spring and remove the spilt keeper.
NOTE: To prevent loss of tension, do not
Compress the valve spring more than
necessary.
Remove spring retainer and spring.
NOTE: The valve springs should be
positioned with the tightly wound coils against
the cylinder head on progressively wound
springs (A).
