42
6.3 CYLINDER REMOVAL
Remove bolts (A) and tap the cam support tower
with a plastic hammer until loose.
After removing the camshaft and securing the
cam chain, tap cylinder head lightly with a
plastic hammer until loose.
Remove the cylinder head and head gasket.
Remove cam chain guide at front of cylinder.
Remove the two 6 mm cylinder base bolts.
Tap cylinder lightly with a plastic hammer in
reinforced areas only until loose.
Rock cylinder forward and backward and lift
it from the crankcase, supporting piston and
connecting rod.
