Aeon Cobra 220 User Manual

6
2. Maintenance
2.1 Maintenance data
2.2 Maintenance schedule
2.3 Throttle operation
2.4 Air cleaner maintenance
2.5 Spark plug
2.6 Idle speed setting
2.7 Drive chain adjustment
2.8 Brake system adjustment
2.9 Wheels and tires
2.10 Steering system
2.11 Toe-alignment
2.12 Transmission lubrication
2.1 MAINTENANCE DATA
SPECIFICATION
SPARK PLUG
Spark plug cap
Recommended spark plugs
Throttle lever free play:
Idle speed
Brake lever free play:
Drive chain slack
Front/rear tire size
Front/rear tire pressure
Toe-in
TORQUE VALVES
SPARK PLUG
TIE-ROD LOCK NUT
ENGINE OIL
Viscosity:
GEAR LUBRICATION OIL
Viscosity:
0.6-0.7mm
N
GK CR7HSA
5-10mm
1500±100rpm
10~20mm
15-25mm
21×7-10 / 20×10-9
4±0.3psi (0.2 kgf/cm
2
)
5±10mm
12-14 N.m
35-43 N.m
SAE 15W-40
SAE 85W-140
