TheControlPanel
Theprinterisreadytoprintwhenthecontrolpaneldisplays PrinterOnline .TheDataand
StatusLEDstogetherwithmessagesindicatetheprinterstatusandanypotential
problems(Table1).
Thecont
rolpanelalsoshowstheestimatedlevelsoftheinkcartridges.Intheexample
below,theyellowinkcartridgelevelisbetween25to50%.
Theic
onsabovetheprinterbuttonsindicatetheirfunctions,whichchangedepending
onthecurrentoperation(seeTable2).
Table1PrinterLEDs
Printerisreceivingdatafromthecomputer.
Thereareprintjobsintheprintermemory.
Printer Online
PowerLED
PowerButton
PrinterButtons
DataLED
StatusLED
InkStatus
LED Description
DataLED
Blinking
On
StatusLED
Blinking •Printheadisbeingser viced,or
• Attentionneeded;amessagewillbedisplayed.(SeeIfError
MessagesAppearonpage68.)
On •Anerrorhasoccurred;amessagewillbedisplayed. (SeeIf
ErrorMessagesAppearonpage68.)
