Afinia L901 - Load Sample Media

Setting Up the Printer 17
Loadsamplemedia
5
b
a
c
d
f
g
Slidelabelguidetoedgeoflabel.
Tightenknobfully
e
Flatsideagainstmediaroll.
OpenMediacover
Loosen
tensionknob
RemoveMediastop
InstallMediaroll
Threadmediaarounddancerandintoprinter
CloseMediacover
Waitforprintertoloadmedia.
Insertmediauntilitstops.
Pushmediaroll
againstinnerguide
