Afinia L901 - Replacing the Printhead

L801LabelPrinter
Printer Maintenance 53
ReplacingthePrinthead
1. Opentheprintertopcover.
2. Onthecont
rolpanel,select ( Config ) > Printhead >
Replace . Waitfortheprintheadlatchtobereleased,then
openthelatchfully.
3. Holdth
eprintheadbythehandle andpushittowardtheprintheadlatch.Oncethe
printheadisreleased,liftitoutoftheprinter.
NOTE: Disposeoftheoldprintheadaccordingtolocalregulations.
Donotopenlatchbefore
itisreleased!
ReplacetheNozzleCover
ontotheremovedprinthead.
