Afinia L901 - Preventive Maintenance Guidelines

50 Printer Maintenance
Afinia
GuidelinesforPreventiveMaintenance
Recommendedmaintenancedependsontheprintmodethatismostfrequentlyused.If
youmostlyprintRolltoRoll(≥80%),referto
Table3.Otherwise,seeTable4.Inspect
meanstochecktheconditionandreplaceifnecessary.
Notethatthesearegeneralguidelinesforpreventivemaintenance.Asoperating
conditionsforyourprintermaydiffer,adjustyourmaintenancescheduleaccordingly.
Maintenanceitemsnotonthetablesbelowshouldbeperformedonanas‐needed
basis.Thesemaintenanceitemswillbecoveredbeforethescheduledmaintenance.
NOTE: Whenusingthecuttingfeatureandcontinuousmediaordie‐cutmediawiththe
outermatrixleftinplace,theprintzoneandcuttingzoneshouldbeinspected
fordustanddebrisevery3rollsandcleanedasneeded.
Table3MaintenanceSchedule:For≥80%
RolltoRollOperation
Part PartNumber Every1Minches
(25,400m)
Every2.5Minches
(63,500m)
Every5Minches
(122,500m)
Sensors –Clean – –
MediaGuide – Clean – –
ServiceStation 22929 Inspect Replace –
AerosolFanGuard 22943 – Replace –
WasteInkAbsorber 22936 – – Inspect
1
1. Inspectionshouldoccurevery20cartridgesor6months,whichevercomesfirst.
Table4MaintenanceSchedule:For≥80% RolltoCut/PrintandCut/PresentOperation
Part PartNumber Every1Minches
(25,400m)
Every2.5Minches
(63,500m)
Every5Minches
(122,500m)
Sensors –Clean – –
MediaGuide – Clean – –
ServiceStation 22929 Replace – –
AerosolFanGuard 22934 – Replace –
WasteInkAbsorber 22936 – – Inspect
1
1. Inspectionshouldoccurevery20cartridgesor6months,whichevercomesfirst.
