Agilent Technologies 1260 Infinity G1315D User Manual

Agilent 1260 Infinity DAD and MWD User Manual 59
Installing the Module
3
Installing Capillaries
Installation of the Bio-inert Zero Dead Volume (ZDV) Union
The Bio-inert ZDV (p/n 5067-4741) union has two different connectors where
capillaries need to be installed in the correct sequence. Otherwise, an inset of
the union may be damaged and the connection may not be tight.
CAUTION
Potential leak or damage of the Bio-inert ZDV Union.
➔ To avoid leaks or a damage to the Bio-inert ZDV union, follow the procedure below
in the prescribed sequence.
1 Install the capillary at the end marked with a
ring/indentation.
2 Install the second capillary at the other end.
5LQJ
5LQJ
