Agilent Technologies 5977B Series Troubleshooting And Maintenance Guide

254 5977B Series MSD Troubleshooting and Maintenance Manual
9 Parts
Tab le 35 Ferrules for the GC inlet, using standard or self tightening column nuts
Description Part number
• 0.27-mm id, 90%/10%, for 0.10-mm id columns 5062-3518
• 0.37-mm id, 90%/10%, for 0.20-mm id columns 5062-3516
• 0.40-mm id, 90%/10%, for 0.25-mm id columns 5181-3323
• 0.47-mm id, 90%/10%, for 0.32-mm id columns 5062-3514
Figure 69 GC inlet with self tightening column nut
GC inlet with self
tightening nut
