5 of 6
Jun 2001
Site Preparation
Agilent 6890 Gas Chromatograph Service Manual
Environmental 510
Benchtop space requirements
Table 510-1 Dimensions, Power, Heat Production, and Weight
Instrument Height Width Depth Power (VA) Heat Weight
6890 Gas Chromatograph
EPC version 50 cm
20 inche
s
59 cm
23 inches
54 cm
21 inches
2,250 8,100 KJoules
7,681 Btu/hr
50 kg
112 lb
Non-EPC version 50 cm
20 inche
s
68 cm
27 inches
54 cm
21 inches
2,250 8,100 KJoules
7,681 Btu/hr
56.8 kg
125 lb
Fast heating oven,
same for EPC and non-EPC
— — — 2,950 10,620 KJoules
10,071 Btu/hr
—
Automatic Liquid Sampler
G1512A Controller (7673) 10 cm
4 inches
33 cm
13 inches
38 cm
15 inches
320 max 545 KJoules
515 Btu/Hr
7.3 kg
16.0 lb
G1513A or G2613A Injector 44 cm above GC
17 inches above GC
18596 or G2614A Tray 31 cm left of GC
9 inches left of GC
Computer*
Computer with monitor 54 cm
21 inche
s
42 cm
17 inches
39 cm
15 inches
N/A N/A N/A
Keyboard 5cm
2 inches
47 cm
18 inches
18 cm
7 inches
N/A N/A N/A
5972A Mass Selective
Detector
35 cm
14 inche
s
17 cm
7inches
65 cm
26 inches
254 max 3,158 Btu/hr,
3,000 with GC
22.7 kg
50.0 lb
7694 Headspace Sampler 31 cm
16 inche
s
56 cm
22 inches
39 cm
22 inches
420 max 2,215 KJoules
2,100 Btu/hr
35.8 kg
79.0 lb
Printer** 30 cm
12 inche
s
42 cm
16 inches
40 cm
16 inches
300 max N/A 16.8 kg
37.0 lb
Integrators
3397 Series,
3396 Series III and,
3395 Integrators
13 cm
5 inches
46 cm
18 inches
46 cm
18 inches
50 135 KJoules
120 Btu/hr
4.3 kg
9.5 lb
35900C/D/E Analog-to-
Digital Converter
11 cm
4 inches
33 cm
13 inches
29 cm
11 inches
40 216 KJoules
205 Btu/hr
4.1 kg
9.0 lb
* General specifications for a mid-size, desktop computer
** General specifications for a typical printer
