13 of 14
Jun 2001
Cabling Configuration and Electronics
Agilent 6890 Gas Chromatograph Service Manual
Cabling Diagrams, 6890A and 6890 Plus 1010
6890 GC External Events (an unspecified, non-Agilent instrument)
6890 GC
External Events
(an unspecified, non-Agilent instrument)
Figure 1010-13
Number Part no. and description
1 G1530-60590, External events cable, 8-pin/spade lugs
Part no. G1530-60590 external event cable spade lug identification
Pin Color Signal
1 Yellow 24 V Out 1
2 Black 24 V Out 2
3 Red Ground
4 White Ground
5 Orange Contact 1
6 Green Contact 1
7 Brown Contact 2
6 Blue Contact 2
6890 GC
Unspecified,
1 External event
non-Agilent
instrument
To Next Page
