1140 Typical Valve Configurations
8 of 10
Jun 2001
Valves
Agilent 6890 Gas Chromatograph Service Manual
Column
Detector
or 2nd
Valve
Carrier
Out
In
Sample
Loop
ONOFF
Gas Sampling with Backflush to Detector, Option 802 or 832
Out
In
Carrier
Out
In
Loop 1
Sample 1
Sample 2
Loop 2
Detector
or 2nd Valve
ONOFF
Gas Sampling of Alternate Streams, Option 803 or 833
