5 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Inlets 1310
Split/splitless inlet column liners
Split/splitless inlet column liners
The table below lists some of the liners available for the split/splitless column.
Refer to the Agilent chemical analysis consumables and accessories catalog
for a complete list of liners and the specifications for each.
Split/splitless inlet EPC pneumatic module
(Part no. G1544-60500, 0 to 100 psig or G1544-60540, 0 to 150 psig)
For diagram of screw and O-ring placement in pneumatic modules see
Figure 1310-7 on page 15 of this section.
Description Part no. Qty.
Single-taper liner with glass wool packing, deactivated
(recommended)
5062-3587 1
Single-taper liner without glass wool packing,
deactivated
5181-3316 1
Split/Splitless liner 19251-60540 1
Split liner, deactivated (recommended) 5183-4647 1
Description Part no. Qty.
1. Male connectors 1/8-inch Swagelok G1543-80030 2
2. Screw, M4 x 45 mm, Torx T-20 0515-2484 1
3. Inlet supply fitting G1543-20610 1
4. Screw, M3 x 12 mm, Torx T-10 0515-1084 2
5. O-rings, under connectors and fitting (12/pkg) 5180-4182 1
6. Split vent On/Off valve G1544-60580 1
