11 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Inlets 1310
Capillary injection port (0 to 30 psig)
Capillary injection port (0 to 30 psig)
Capillary injection port subassembly (0 to 30 psig)
(Part no. G1544-65500)
See also the parts list for the Split/Splitless Inlet with EPC.
Description Part no. Qty.
1. SCR-Mach M4 × 0.7 × 8 mm LG 0515-0106 2
2. SCR-Mach M4 × 12 mm, T-20 Torx 1390-1023 3
3. Thread cutting screw 0624-0665 2
Description Part no. Qty.
1. O-ring.239-inch (Order no. 5180-4182 12/pkg) 0905-1014 1
2. SCR-M4 × 8 T-20 Torx-chrm plt 0515-2711 2
3. Reducing nut 18740-20800 1
4. Column nut 5181-8830 2/pk
5. Gold plated seal 18740-20885 1
6. Septum nut assembly 18740-60835 1
7. Vent torque plate 19244-00030 1
8. Purge regulator 19246-60530 1
9. Insert assembly series II 19251-60575 1
10. Washer, flat SS 5061-5869 12/pk
11. 11-mm Solsept (Order no. 5182-0739) 50/pkg
12. Ferrule, no hole 5181-7458 1
13. Cap top insulation G1544-00010 1
14. Flow controller inlet fitting-replacement 0100-1595 1
15. Cap inlet block insulation G1544-00020 1
16. Cap bottom insulation G1544-00030 1
17. Cap heated block G1544-20570 1
18. Cap thread insert G1544-20580 1
19. Cap thermal nut G1544-20590 1
20. S/S Solenoid cable assembly G1544-60520 1
21. Cap solenoid valve G1544-60560 1
22. Cap inj. heater/sensor assembly G1544-61140 1
23. Cap shell weldment G1544-80570 1
NS Replacement flow controller O-ring kit 0905-1251 –
