1310 Inlets
Purged/packed inlet
12 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Purged/packed inlet
Description Part no. Qty.
1. Screws, Torx T-20, M4 × 12 mm 0515-2496 3
2. Top cover plate G1543-00085 1
3. Top insulation G1543-00100 1
4. Septum nut 18740-60835 1
5. Septum, 11 mm, low bleed (50/pkg) 5182-0739 –
6. Nut, Merlin Microseal 5182-3445 –
7. Septum, Merlin Microseal 5182-8815 –
8. Top insert weldment 19243-80570 1
9. Viton O-ring (Pkg/12) 5080-8898 1
10. Heater/Sensor assembly G1543-61540 1
11. Screw, Torx T-10, M3 × 16 mm 1390-1022 1
12. Inlet weldment G1543-80580 1
13. Top gasket insulation (not shown) G1543-00155 1
14. Thermal block G1543-20765 1
15. Bottom nut G1543-20580 1
16. PPIP insulation G1543-00030 1
17. PPIP bottom insulation G1543-00070 1
18. Glass insert (pkg/25) 5080-8732 1
19. Vespel ferrule (pkg/10) 5080-8774 1
20. Tubing nut (1/4-inch brass) 5180-4105 10/pkg
21. 530 µ Column liner (see the Agilent chemical analysis
consumables and accessories catalog)
19244-80540 1
1/8-inch Column adapter (optional) 19243-80510 –
22. Nut warmer insulation 19234-60715 3
23. Nut warmer cup 19234-60700 1
24. Ferrules (identify by internal diameter):
Solid ferrule plug (no hole) 5181-7458 1
Graphite ferrule 0.5 mm ID 5080-8853 10/pkg
Graphite ferrule 1.0 mm ID 5080-8773 1
25. Column nut (Order no. 5180-8830 2/pkg 18740-20870 1
