1310 Inlets
Purged/packed inlet EPC pneumatic module
14 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Purged/packed inlet EPC pneumatic module
(Part no. G1543-60500)
For diagram of screw and O-ring placement in pneumatic modules see
Figure 1310-7 on page 15 of this section.
Description Part no. Qty.
1. 1/8-inch Swagelok male connector SAE, brass G1543-80030 1
2. Inlet fitting G1543-20610 1
3. Screw, M4 × 45 mm, Torx T-20 0515-2484 1
4. O-rings,.239 id (order part no. 5180-4182, 12/pkg) 1
5. PPIP/EPC inlet manifold kit, not shown G1543-65520
