1310 Inlets
Purged/packed inlet manual pneumatic module and inlet
16 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Purged/packed inlet manual pneumatic module and inlet
(Part no. G1543-65505)
Packed Inlet Optional Flow Restrictors
Description Part no. Qty.
1. Mass flow controller, 0 to20 mL/min 19362-60565 1
2. Gauge jumper weldment 19243-80555 1
3. Purge vent tube weldment 19244-80580 1
4. Pressure gauge spacer 19243-40010 1
5. Pressure gauge (0 to 100 psi) 19361-60565 1
6. Flow module bracket 19245-00105 1
7. Septum purge regulator 19243-60650 1
8. Chemical trap assembly 05980-80710 1
9. M8 O-ring, ungreased 5180-4181 10
10. M8 plastic fitting 5181-3394 10
11. Vent torque plate 19244-00030 1
12. Hex nut, 5/16-inch 2950-0203 1
NS Fitting, MFC/PPIP adapter G1543-20540 1
NS PPIP/PCOC MNL-EPC adapter assy G1545-80510 1
NS Blank label plate G1530-90705 1
NS PPIP label plate G1530-90740 1
NS Torx screw, M3 × 16, T-10 1390-1022 1
NS Torx screw, M4 × 12, T-20 1390-1023 3
Colored dot code Supply pressure Flow range (mL/min) Part no.
Red and purple 50 0 to 20 19362-60515
Blue and purple 50 0 to 60 19362-60525
Green and purple 50 0 to 110 19362-60535
