1310 Inlets
Programmed temperature vaporization inlet calibrated manifold assembly
24 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Programmed temperature vaporization inlet calibrated
manifold assembly
(part no. G2617–60500)
For diagram of screw and O–ring placement in pneumatic modules see
Figure 1310-7 on page 15 of this section.
Description Part no. Qty.
1. PTV thermocouple PCB G2617-60010 1
2. PTV thermocouple PCB cable G2617-60505 1
3. Calibrated manifold assembly G2617-60500 1
4. Male connectors 1/8-inch Swagelok G1543-80030 2
5. Inlet fitting block G1543-20510 1
