1310 Inlets
Volatiles interface
28 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Volatiles interface
Description Part no. Qty.
1. VI top cover G2319-00020 1
2. Top insulation G2319-20580 1
3. Screw, M4 x 12 1390-1023 4
4. Clamping plate G2319-20540 1
5. Volatiles interface G2319-60505 1
NS Ferrule, 1/16-inch, (10/pk) 0100-1333
NS Blanking nut 1/16-inch SS 01080-83202
NS Male nut, 1/16-inch 0100-0929
6. VI heater/sensor assy G2319-60503 1
7. Heater block assy G2319-60507 1
8. VI insulation htr block G2319-20530 1
9. Pneumatic gang fitting assy G2319-60501 1
Contains:
Gen. make-up restrictor 19243-60540 1
O-ring 0905-1014 1
To r x s c r e w 1390-1024 2
Replacement filter kit G1544-80530 —
or
10. Filter trap assy (not shown) G2319-80530 1
11. RP filter G1544-80530 2/pk
12. Nut, male 1/16-inch swage 0100-0929 3
13. Vol. front trap assy G2319-80530 1
14. Trap nut G1544-20650 1
