1350 Valves
Valco W-series minivalve
10 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Valco W-series minivalve
Description Part no. Qty.
1. Valve
Gas sampling valves
– 6-port valve (225°C max) 5062-9508
– 6-port valve (350°C max) 0101-0584
– 6-port valve (Hastelloy, 225°C max) 5062-9509
– 10-port valve (225°C max) 5062-9510
– 10-port valve (350°C max) 0101-0585
– 10-port valve (Hastelloy, 225°C max) 5062-9511
Liquid sampling valves
– 4-port valve (internal sample injector)
(0.2 µl, 1000 psi, Option 850)
0101-0636
– 4-port valve (internal sample injector)
(0.5 µl, 1000 psi, Option 852)
0101-0637
– 4-port valve (internal sample injector)
(1.0 µl, 1000 psi, Option 854)
0101-0638
– 4-port valve (internal sample injector)
(0.5 µl, 5000 psi, Option 856)
0101-0639
2. Ferrule 0100-1022
3. Nut 0100-0791
4. Rotors:
General purpose valve rotors
– 6-port valve (225°C max) 5181-7459
– 10-port valve (225°C max) 5181-7460
– 6-port valve (350°C max) 1535-4952
– 10-port valve (350°C max) 1535-4954
Standard pressure liquid sample valve rotors
– 0.2 µl 4-port (1000 psig max) 5062-3563
– 0.5 µl 4-port (1000 psig max) 5062-3562
– 1.0 µl 4-port (1000 psig max) 5062-3559
