1350 Valves
Nickel catalyst assembly
12 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Nickel catalyst assembly
Description Part no. Qty.
1. Nickel catalyst assembly G1580-61020 1
2. Screw—socket M4 × 20 0515-0038 2
3. Nickel catalyst heater/sensor assembly G1580-61160 1
4. Nickel catalyst H
2
mix FTG weldment G1580-80500 1
5. Nickel catalyst heater block 18900-20835 1
6. Nut—hex with lockwasher 0535-0043 2
7. Screws, Torx T-20, M4 × 12 mm (captive) 1390-1023 3
8. Top cover plate G1543-00085 1
9. Top insulation G1543-00100 1
10. PPIP Insulation G1543-00030 1
11. PPIP Bottom insulation G1543-00070 1
12. Nut warmer insulation 19234-60715 3
13. Nut warmer Cup 19234-60700 1
