100 Maintaining Your GC
6 Maintaining the Packed Column Inlet
5
Insert the adapter straight into the inlet base as far as
possible.
6 Hold the adapter in this position and finger-tighten the nut.
7 Tighten an additional 1/4 turn with a wrench.
Inlet fitting
Ferrule
Tubing nut
Adapter
