124
Maintaining Your GC
7
Maintaining the COC Inlet
Exploded Parts V
iew of the COC Inlet
Septum nut
(0.53 mm)
Septum nut
(0.25-mm and 0.32-mm
columns)
Septum
Spring
Insert
Ferrule
Column nut
Cooling tower assembly
Duckbill septum
123
125
