196
Maintaining Your GC
10
Maintaining the µECD
Exploded Parts V
iew of the µECD
V
ent line
W
arning tag
Perforated cover
Electrometer
Ferrule
Adapter nut
Cap
Liner
Insulation
Makeup gas adapter
Insulation cup
Ferrule
Column nut
195
197
