Maintaining the FID 8
Maintaining Your GC 147
Column cutter, ceramic wafer Cutting capillary columns 5181-8836 (4/pk)
Pencil, diamond tipped Cutting capillary columns 420-1000
Ferrule tool kit Ferrule installation 440-1000
Table 19 Nuts, ferrules, and hardware for capillary columns (continued)
Column id (mm) Description Typical use Part number/quantity
Table 20 FID parts and subassemblies
Description Part number/quantity
Screw, M4 × 25 mm, Torx, T20 0515-2712 (3/pk)
PTFE chimney (optional) 19231-21050
Collector assembly G1531-60690
FID/NPD capillary column adapter 19244-80610
FID/NPD 1/8-inch packed column adapter 19231-80520
FID/NPD 1/4-inch packed column adapter 19231-80530
Insulation 19234-60715 (1/pk)
Insulation cup assembly 19234-60700
Nut, 1/4-inch, brass, for packed column adapters 5180-4105 (10/pk)
Ferrule, Vespel, 1/4-inch, for packed column adapters 5080-8774 (10/pk)
Table 21 Jets for capillary adaptable fittings
Jet type Part number Jet tip id Length
Capillary 19244-80560 0.29 mm (0.011 inch) 61.5 mm
Capillary, high-temperature
(use with simulated distillation)
19244-80620 0.47 mm (0.018 inch) 61.5 mm
Packed 18710-20119 0.46 mm (0.018 inch) 63.6 mm
Packed, wide-bore
(use with high-bleed applications)
18789-80070 0.76 mm (0.030 inch) 63.6 mm
Table 22 Jets for capillary optimized fittings
Jet type Part number Jet tip ID Length
Capillary G1531-80560 0.29 mm (0.011 inch) 43 mm
High-temperature
(use with simulated distillation)
G1531-80620 0.47 mm (0.018 inch) 48 mm
