150 Maintaining Your GC
8 Maintaining the FID
Jet
FID column adapter
(Adaptable FID only;
capillary adapter shown)
Insulation
(Adaptable FID only)
Insulation cup assembly
(Adaptable FID only)
25-mm
screws
Collector
assembly
Collector nut
Spring washer
Ignitor
Upper collector
insulator
Collector body
Spanner nut
(collector)
Collector mount
Lower collector
insulator
Collector
housing
Gasket
Ignitor (glow plug)
assembly with O-ring
Ignitor cable
assembly
