152 Maintaining Your GC
8 Maintaining the FID
Table 25 Jets for capillary adaptable fittings
Figure 2 ID Jet type Part number Jet tip id Length
1 Capillary 19244-80560 0.29 mm (0.011 inch) 61.5 mm
2 Capillary,
high-temperature
(use with simulated
distillation)
19244-80620 0.47 mm (0.018 inch) 61.5 mm
3 Packed 18710-20119 0.46 mm (0.018 inch) 63.6 mm
4 Packed, wide-bore
(use with high-bleed
applications)
18789-80070 0.76 mm (0.030 inch) 63.6 mm
Figure 3 Capillary adaptable jets
