1a-5
Operation Examples
Incrementing or Decrementing the RF output Signal
Incrementing or Decrementing the RF output Signal
In this example, you will increment the amplitude and frequency of the RF output signal.
Preliminary Steps
1. If they are not already set, set the frequency to 100 MHz and the amplitude to
−100 dBm.
Using the Knob
2. Increment the amplitude using the knob.
Press ⇐ or ⇒ when you wish to adjust the increment resolution.
Using the Increment Keys
3. Enter a frequency increment of 25 kHz
The symbol is displayed when you press
INCR SET to indicate that the displayed
value is the increment set value.
