7-61
Adjustments
Agilent Service Support Software
Instrument Serial Number (1): Enter the complete serial number of the instrument
that has been changed.
Instrument Model Number (2): Select the model number of the instrument that has
been changed. Only one model number may be selected.
Attenuator ID Number (3): For 8648B/C/D models only, enter the last four digits of
the A11 attenuator serial number. For 8648A, these fields are given a default state of
not applicable (N/A0 and may not be changed.
Options Installed (4): Select all options that are actually installed in the instrument
that has been changed. More than one may be selected. Any options that are not
available with the instrument model number selected are grayed out and are not
accessible. Select the correct instrument model number before selecting the options
installed.
CAUTION Selecting options that are not actually installed in the instrument will cause
erroneous information to be saved in the motherboard and will affect the
instrument calibration.
CAUTION Once the Send Data button is selected, the download process is started and
can not be stopped. Calibration data will be erased and a complete calibration
will be required.
4. When you have finished entering the information for the instrument that has been
changed, download it to the motherboard by selecting the Send Data button.
The download process can take several minutes to complete. A progress indicator will
be displayed.
5. Once the information has been stored in the motherboard, select the Get Data button to
read what is stored in the motherboard. If the information is not correct, repeat steps 3
and 4.
6. After the correct information has been stored in the motherboard, select Cancel to exit.
