Performance Tests
8648B Test Record
Table 8-31. Phase Modulation Distortion Performance Test - Part 1
Frequency
(MHz)
Deviation
(Rad)
Limits (%)
Uncertainty
(%)Lower Measured Upper
0.250 5 0 1 0.26
100 5 0 1 0.26
400 5 0 1 0.26
500 5 0 1 0.26
750 5 0 1 0.26
1000 5 0 1 0.26
Table 8-32. Phase Modulation Distortion Performance Test - Part 2
RF
Frequency
8648B
(MHz)
LO
Frequency
8663A
(MHz)
Input
Frequency
8902A
(MHz)
Deviation
(Rad)
Limits (%)
Uncertainty
(%)
Lower Measured Upper
1500 1501.5 700 7 0 1 0.26
2000 2001.5 700 7 0 1 0.26
Table 8-33. Residual FM Performance Test
RF Frequency
8648B
(MHz)
LO Frequency
8663A
(MHz)
Input Frequency
8902A
(MHz)
Limits (Hz)
Uncertainty
(±Hz)Upper Measured
10 11.5 700 7 0.45
100 101.5 700 7 0.45
248 249.5 700 7 0.45
251 252.5 700 4 0.35
400 401.5 700 4 0.35
501 501.5 700 7 0.45
750 751.5 700 7 0.45
1000 1001.5 700 7 0.45
1500 1501.5 700 14 0.75
